Overview
The GE2015 Dev Board provides a complete solution based on the data functions of the CDMA, GSM, WCDMA and LTE modules for debugging and testing. With an extra interface board, the Dev Board not only reduces all module function pins (such as power supply, UART, USB and so on) but also adds the right amount of testing points to provide all kinds of simple and convenient interfaces for users.
Highlights
- One RS232 4-wires UART, one 2-wires debug UART
- One SPI to UART interface
- Two UART to USB interface
- Can adapt to 1.8V/3.3V level
- Power supply can be switched between USB supply and DC power supply
