* Embedded GOSUNCNWelink LTE wireless module
* GR500-U (North America):
LTE FDD: B2/B4/B5/B12/B17 WCDMA: B2/B5 GSM: B2/B5* Supports 802.11b/g/n, 2T2R 2.4 GHz with 300 Mbps PHY data rate
* Support Wi-Fi AP,AP Client,Repeater,Repeater Bridge and WDS work mode(optional)
* Support WEP,WPA,WPA2 way of encryption,support RADIUS certification, MAC adress filter function
* Support GPS function by independent GPS chipset
* Industrial grade 32-bit communication processor
* 16MB
* 64MB
* 2X10/100M Ethernet interface (RJ45), MDI/MDIX auto-negotiation, embedded 15KV ESD protection
* 1Xconsole RJ45 socket ,embedded RS232 interface (or RS422/RS485), embedded 15KV ESD protection:
* Data bit:5、6、7、8 bit
* Stop bit:1、2 bit
* Calibration: no calibration, odd/even parity
* UART speed: 300~115200bits/s
* PWR, VPN, SYS, PPP, BAK, SIG, LAN 1, LAN 2
* ANT1 : 3/4G AUX, norm SMA negative antenna interface, characteristic impendence is 50 ohm
* ANT2: : Wi-Fi ,negative antenna interface, characteristic impendence is 50 ohm (optional)
* ANT3 : GPS/Wi-Fi ,norm SMA negative antenna interface, characteristic impendence is 50 ohm(optional)
* ANT4: : 3/4G MAIN, SMA negative antenna interface, characteristic impendence is 50 ohm
* Normal drawer type card interface (1.8V/3V SIM/UIM card), embedded 15KV ESD protection
* Normal 3-core power socket, embedded power reverse-phase protection and overvoltage protection
* Revert ROUTER parameters to factory ones
* DC 12V/1A
* DC 6~35V
* <500ma (12V)
* Metal shell, IP 30 level of protection, safe isolation from inner system, suitable for industrial field application
* 118x100x22 mm (antenna and installation parts are not included)
* About 357g
* -25~+65℃(-13~+150℉)
* -30~+75℃(-22~+167℉)
* -40~+85℃(-40~+185℉)
* 95% (non-condensing)
