Overview
The following shows multiple scenarios where R800 industrial wireless routers are applied:
Self-service Terminal Networking
R800 industrial wireless routers allow you to conveniently implement wireless networking and remote management of self-service terminals. Operators can greatly increase the business transaction volume by deploying self-service devices in any area covered by wireless networks, such as shopping malls, streets, and neighborhoods.
System Diagram
Public Bicycle Management
The public bicycle lease system consists of a management center, customer service stations, and bicycle lease stations. The R800 is applied in the communication management system of the management center to implement data forwarding, transmission, and transit between the lease management system and the background by using carrier networks.
System Diagram
Remote Video Surveillance in Smart Grids
Remote video surveillance systems have been widely used in the intelligent monitoring of power transmission lines. The system implements video surveillance on power transmission lines, all levels of towers and power transmission and transformation devices, and video data information is transmitted to the management center by using the R800. The real-time monitoring on the status of power transmission lines improves lean production management.
System Diagram
Remote Monitoring and Maintenance on Medical Treatment
The R800 industrial wireless router is connected to CT/MR equipment and sets up and sends an IPSec VPN security tunnel to the medical maintenance equipment. This greatly ensures data security. Maintenance personnel can monitor the temperature and humidity of CT/MR equipment and the loss of spherical tanks in real time. The cloud platform can simultaneously manage tens of thousands of routers and master the operating information of all equipment in hospitals.
System Diagram
Remote Monitoring and Maintenance on Central Air Conditioners
The R800 industrial router has a built-in 10/100 Mbit/s Ethernet interface, which is connected to one or more Ethernet PLCs on the air conditioning site to form an air-conditioning field network. It also establishes a cryptographic secure tunnel with the "VPN Firewall" at the front end of the air conditioner manufacturer's monitoring center, thus seamlessly connecting the "air conditioning field network" and the "air conditioner manufacturer's monitoring center". In this way, the engineering maintenance personnel can change the configurations of field devices by directly gaining access to the actual IP address of the equipment in the "air conditioning field network."
System Diagram
Remote Monitoring on Sanitary Sewage Stations
R800 industrial routers consolidate information about sewage treatment equipment at different sites and sent it to the enterprise's data monitoring center by using 3G/4G wireless networks. The central software analyzes and diagnoses equipment status and faults, helping users to grasp the equipment usage and assets status.
System Diagram
Smart Charging Pile Solution
The wireless data transmission solution for charging piles consists of four parts: an electric vehicle, a charging pile, a router, and a third-party M2M cloud management platform. R800 routers can establish high-speed and stable networking and data transmission channels in the transmission solution. All charging and payment information is transmitted to the background of the operating enterprise for business analysis and operation.
System Diagram
Highlights
- It facilitates wireless networking and remote management of self-service terminals and greatly increases the business transaction volume when it is deployed in areas covered by wireless networks, such as shopping malls, streets, and neighborhoods.
- The central software analyzes and diagnoses equipment status and faults, helping users to grasp the equipment usage and assets status.
- All charging and payment information is transmitted to the background of the operating enterprise for business analysis and operation.
- Data forwarding, transmission, and transit are implemented between lease management systems and the background by using carrier networks.
- The cloud platform allows you to simultaneously manage tens of thousands of routers and master the operating information of all equipment in hospitals.
- The real-time monitoring on power transmission lines improves lean production management.
Applications
R800 industrial data transmission UE solution has been widely used in the M2M industry in the Internet of Things industry chains, for example, smart grids, smart transportation, smart home, finance, mobile POS terminals, supply chain automation, industrial automation, smart building, fire protection, public safety , environmental protection, meteorology, digital medical treatment, remote sensing, military industry, space exploration, agriculture, forestry, water, coal industry, and petrochemical industry.
- Self-service terminal networking and public bicycles in the transportation field
- Smart charging piles and smart grids
- Remote monitoring and maintenance on medical treatment
- Remote monitoring and maintenance on central air conditioners
- Sanitary sewage station
