* LCC Form Factor (80 pins)
* Pin-to-Pin with LCC 30*30
* Dimensions: 30mm × 30mm× 2.3mm
* Weight: About 4.3g
* Frequency Band:
--CDMA2000 1X/EVDO 800MHz
* Transmit Power:
--CDMA : 24 +1/-1 dBm @ All up bits
* Receiving sensitivity:
--CDMA : <-110dBm
* Power Supply :
--3.3V-4.2V (3.8V is recommended)
* Power Consumption:
--Sleep : 3.46mA@RX:-75dBm (Typical)
--Call : 184.4mA@RX:-75dBm (Typical
* CDMA2000 EVDO
--Uplink 1.8Mbps / Downlink 3.1Mbps
* CDMA2000 1X
--Uplink 153.6 kbps / Downlink 153.6 kbps
* Support Text and PDU mode
* Point to point MO and MT
* SMS Status Report
* Management of SMS
* USB 2.0 full-speed
* SIM interface (1.8/3.0V DC)
* UART(8-wires)
* SPI
* I2C
* ADC
* Antenna (RF PAD for Primary, Diversity)
* LED indication
* Reset & Power-on
* WAKE-IN & WAKE-OUT
* 1.8/2.6V output ref voltage
* Support embedded TCP & UDP protocols
* Support protocols PAP and CHAP used for PPP connection
* SMS & MMS & Phonebook
* Improved power-saving mode
* USB Selective Suspend & Remote wakeup
* Control Via AT Commands
* Drivers
--Windows XP, Vista, 7
--Linux
--Android
* Diag-log Tool for Windows, Android, Linux
* Firmware Update Tool
